Positive 12864 Dots Matrix STN HTN FSTN COG Graphic LCD Display Module

Ask Lasest Price
Brand Name :	Qihang
Model Number :	JXL-12864COG1M2 LCM
Certification :	ROHS/CE
Price :	Negotiable
Payment Terms :	T/T, L/C, D/A, D/P, Western Union, MoneyGram, paypal
Supply Ability :	300000 Per Month
Delivery Time :	10-15 Days

Add to Cart

Product Details
Company Profile

Positive 12864 Dots Matrix STN HTN FSTN COG Graphic LCD Display Module

STN HTN FSTN COG Graphic LCD Display Module

Product Details

JXL-12864COG1M2 is a dot matrix LCD module, It can display 128*64 dots size LCD panel. It can be used in graphic display modes, and includes various attribute functions. The device has an 8-bit parallel data bus and control lines for reading or writing through an MPU interface.

Features

Display format128*64 dot matrix
STN (yellow_green) positive mode
Easy interface with 8-bit MPU
Low power consumption
Viewing angle: 6 O’clock
Multiplex level: 1/64 duty, 1/9 bias
LCD driving voltage (top):9.0
LCD driver IC / LCD controler: ST7565R

Name	STN HTN FSTN COG Graphic LCD Display Module
Applicaion	All kinds of meter
Display Content	128x64 DOTS
Operating voltage	5.0 V
Driving method	According to your request
Viewing angle	6 O'clock
Display mode	Positive
View Area	65.40 (L)*38.0 (W)mm
Outside Dimensions	91.40 (L)61.30 (W)10.0 (H) mm
Voltage driving	Dynamic or static
Connector	COG + FPC
Drive Method	1/65 Duty, 1/9 Bias
Polarizer Type	Transflective
Package	COG
OEM/ODM	Accecpted
System design	Lcd module related system software and hardware design accepted
Warranty	12 months free, payed warranty lifttime
Backlight	White LED
LCD Module type	Graphic LCD Module
Sample lead time	3-7 working days
Customize lead time	15-30 working days
Packaging	One module in a bag, bags in small carton foam protecting, small carton in big carton
Cetification	ISO,SGS
