Product features:
Operating temperature : -30℃ - + 80℃
Storage Temperature: -30℃ - + 85℃
View Angle 6 o 'clock, display color: FSTN gray screen
Backlight: green backlight.
Operating voltage 3.3V, backlight 5V, glass voltage VOP=10.5V
Communication method: 8080 parallel port
132*64 dot matrix display
Free to write graphics or Chinese characters
Functional instruction
The column scan order sets the starting row page column address
setting
Display on/off anti-white display
Power control standby mode
Bias ratio setting LCD double voltage setting
Display contrast Settings software reset
Low power saving design (except backlight 6 lamps 15*6= 90mA)
Normal mode (250uA TYP VDD=3.3V)
Standby mode (30uA Max VDD=3.3V)
Display contrast, internal register adjustment (software contrast
adjustment)
Duty:1/65 Bias:1/9
Plug-in FPC, easy to install.
Compatible CMF3P5135 - E V1.0
Product Show
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown
cartons. If you have legally registered patent , we can pack the
goods in your branded boxes after getting your authorization
letters.
Q2. What is your terms of payment?
A: Full payment. Goods would be shipped in 3-5 work days after
payment received, finally depends on quantities.
Q3. How about your delivery time?
A: Generally, goods would be shipped in 3-5 work days after payment
received, finally depends on order quantities.
Q4. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but
the customers have to pay the sample cost and the courier cost.
Q5. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
