Specification
| ITEM | VALUE |
| NUMBER OF GRAPHIC | 192*64 |
| LCD driving voltage (top) | 12.0V |
| EFFECTIVE DISPLAY AREA | 78.5×47.5 |
| LCD driver IC | KS0107 |
| LCD controler | KS0108 |
| DUTY/BIAS | 1/64 duty, 1/9 bias |
| LCD Type | FSTN black-white positive mode |
| Operating temperature | -20 ~ +70 |
| Storage temperature | -30 ~ +80 |
| VIEWING DIRECTION | 6.00 |
| BACK LIGHT COLOR | WHITE |
Shipment
Package
Notice
Handle the protective film
A layer of protective film is pasted on the surface of the finished
module. To prevent contamination of the display surface during
assembly, Do not remove it before the assembly of the whole machine
is completed. Avoid soiling or scratching the display surface.
Precautions during assembly operation
1. The module is carefully designed and assembled. Please do not
process and modify it by yourself.
2. The metal frame claws must not be twisted and disassembled at
will
3. Do not arbitrarily modify the circuit and components of the
assembly hole of the processed PCB board
4. Do not modify the conductive strip
5. Do not modify any internal brackets 6. Do not touch, bend or
twist the module
7. Do not apply uneven force to the PCB board during installation
to avoid distortion of the PCB board. Conductive connection strap
pull up
Strictly prevent static electricity
The control and drive circuits in the module are low-voltage,
micro-power CMOS Circuits are easily broken down by static
electricity, which is an irreparable damage bad, and the human body
sometimes produces high voltage static electricity up to hundreds
of volts or thousands of volts Therefore, extreme care should be
taken in operation, assembly and use, and strict anti-static. to
this end: 1. Do not touch the circuit and metal frame on the outer
lead circuit board with your hands. 2. If direct contact is
necessary, the human body and the module should be kept at the same
potential Or ground the human body well 3. The soldering iron used
for welding and the electric tools used for operation must be well
grounded no leakage 4. Do not use a vacuum cleaner for cleaning as
it produces strong static electricity 5. Dry air will also generate
static electricity, so the humidity in the workplace should be
RH60% about 6. When taking out or putting it back into the bag or
moving the location, care should also be taken to prevent Static
electricity Do not change the package or discard the original
package at will
